4" 1000W Solar Centrifugal Submersible Pump 1600W Solar Panel with 40m Cable & Free Delivery

4" 1000W Solar Centrifugal Submersible Pump 1600W Solar Panel with 40m Cable & Free Delivery

$4,695.00 AUD
$4,695.00 AUD
Sale Sold out

This 4"1000W Centrifugal impeller bore pump produces more water flow, but less pressure. Pump model: THC5-A08-110/1000

Our 4" 1000W solar submersible pump with 40m of cable features an advanced 3-phase brushless stainless steel DC motor, high quality NSK Japanese bearings, adjustable pump speed, integrated soft start and Maximum Power Point Tracking (MPPT). With max flows up to 4,800L/hr at a price that can't be beat, you will quickly see why this pump is one of our biggest sellers.

Built to last in Australia's tough agricultural environment, this pump delivers strong volumes up to 120m of head. Our standard package comes complete with a ton of extras and 8 x 200W solar panels for optimal performance. With our easy DIY installation, you can enjoy years of reliable and maintenance free water supply

NOTE: You have to get below items locally: (package does not include the following)

  1. A stainless steel wire (called safety cable) to hold pump in bore. If pump water from dam or river. A float set up is required.
  2. Panels frames to support solar panels.
  3. Poly pipe from pump to water tank.

Product Inclusions

  • 8 x 200W mono crystalline A grade solar panels.
  • 4" 1000W/110V Centrifugal Multi Stage Impellers Solar Pump A08 fitted with 40m power cable.
  • Pump control box.
  • One spare helical screw rotor.
  • 2 x 2m with MC4 extension cable for solar panels connect to control box.
  • 1 x 40m & 1 x 10m combined water sensor (for bore & water tank).
  • User manual.
  • 24 months (Pump & Control Box) back to base (Sydney) warranty.
  • Free delivery in Australia.

Product Specifications

Pump Specifications:

Pump Power: 1000W/110V-DC
Pump Type: Centrifugal impeller A08
Maxi Head: 110m
Maxi Flow: 80L/min (rated in 110V/DC)
Outlet: 1.25"/32mm
Weight: 16kg
Dimensions: 100mm x 650mm
Maximum Submerge depth: > 30m

Pump recommended NO more than 100m dynamic head.

Head      L/Min     Gal/Hr

100m       15L         200

90m         25L         333

80m         35L         467

70m         45L         600

60m         50L         666

50m         58L         773

40m         62L         827

30m         68L         906

20m         72L         960

10m        80L          1067

Pump Controller Specifications:

  • Water level control of tank and bore by sensors
  • Motor speed adjustable
  • Low power protection
  • Solar and/or batteries power input option
  • MPPT Maximum Power Point Tracking system, Allow input power voltage up to 200V/DC (solar panel open circuit maximum voltage)

Solar Panel Specifications:

  • 200W solar panel dimension: 1580 x 808 x 35mm.
  • Weight: 16Kg.

Options

240V/AC to 110V/Dc Converter
